PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter

PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter
PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter
PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter

Large Image :  PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter

Product Details:
Place of Origin: Shanghai China
Brand Name: PULLNER
Certification: FDA
Model Number: PHFM
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Carton box after poly bag. 4pcs per carton
Delivery Time: 5days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 800pcs per week
Contact Now

PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter

Description
PHFM: PP Pleated High Flow Filter Element RO Security Filter Removal Rating: 1um, 2um, 5um, 10um, 15um, 20um, 30um, 50um, 70um, 100um
Filtration Efficiency: 99.8% Material: Polypropylene
OD: 160mm Filter Area: 6.6㎡
Length: 20"(508mm), 40"(1016mm), 60"(1524mm) Flow Rate: 60m³/h
Max. Operating Temperature: 82℃ Max.. Operating Differential Pressure: 3.5bar@21℃
Highlight:

99.8% 5 micron absolute filter

,

99.8% pleated water filter cartridge

,

6.6㎡ 5 micron absolute filter

160mm Diameter 60" 5 micron absolute 99.8% PP Pleated 6.6㎡ High Flow Filter Element RO Security Filter


General information
PHFM series High flow filter cartridge diameter is 160mm with advanced pleated technology, provide bigger filtration area, high dirt holding capacity.  All connection use thermal welding.

PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter 0



Material Construction

Filter Media

PP: Deep Pleated PP/Melt PP

Support/Drainage

PP

End Cap Material

Fiberglass Reinforced Polypropylene



Filter Performance

Micron 1um, 3um, 5um, 10um, 15um, 20um, 50um, 70um, 100um
Max. operating temperature 82℃
Max. operating differential pressure 3.44bar@82℃
Suggestion pressure for filter replacement 2.5Bar@20℃


Flow Rate and Filtration Area

Size

(Diameter*Length)

Design Flow

(m3/hr)

Maximum Flow

(m3/hr)

Filtration Area

(㎡)

6"*20"

15

40

2.6

6"*40"

30

80

5.2

6"*60"

45

120

7.8



Features

1. Innovative radial pleat technology.
2. 1.5~3 times larger surface area than standard 6" vertical pleate high flow water filter cartridge.

3. "Twist to lock" seating mechanism provides positive seal.
4. Friendly handle design easily for operator change out.
5. Highly consistent performance.
6. 100% constructed by avanced polypropylene media.
7. Widely excellent chemical capacity.
8. Lower initinal pressure drop.


PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter 1



6200㎡ Factory

PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter 2



Global Customers

PP Deep Pleated RO 6.6㎡ 99.8% 5 Micron Absolute Filter 3



FAQ



Q: Are you trading company or manufacturer ?

A: Factory 6200㎡at Shanghai industry area, have our own test laboratory with advanced test facilities for filter and raw material test.

Q: How long of delivery time?

A: 100pcs, 1~3 days

1,000pcs, 5~7days

5,000pcs, 12~15days

If urgent, can be negotiated.

Q: Do you provide sample ? is it free or charge ?

A: Yes, we provide FREE sample for customers, general sent out in 2days.
