Polypropylene Filter Material Pullner Condensate Clarification Max Temperature 85°C
Pullner Condensate Polishing Filter is designed for condensate purification and straining. It utilizes a high-quality filter material, polypropylene, which can withstand a maximum filter temperature of 85°C. The filter area is 0.4-0.7㎡. The product has passed ISO 9001 certification and can provide reliable filtration of condensate for a wide range of applications.The Condensate Polishing Filter is designed to filter the condensate through a series of layers. The top layer is designed to strain any large particles, while the other layers are designed to filter out any impurities. The filter material is strong and durable, making it suitable for long-term usage with minimal maintenance. The filter is also designed to be effective and efficient, reducing the need for frequent replacements. Pullner Condensate Polishing Filter is the ideal solution for condensate filtration and purification. It provides reliable and effective filtration of condensate, ensuring that your condensate is free from any particles or impurities. It is also an affordable and efficient solution, allowing you to save on costs and time.
Material Construction
| Model |
Filter Media |
Support/Drainage |
End Caps |
Seals Material |
| PP |
Deep
Pleated Polypropylene
|
Polypropylene |
Glass
Fiber
Reinforced Polypropylene
|
NBR,EPDM,Viton |
| GF |
Glass Fiber/Polyester |
Glass Fiber/Polyester |
Glass
Fiber
Reinforced Polypropylene
|
Filter Performance
| Micron |
0.1-100um |
| Max. operating temperature |
Pleated Glass Fiber:121℃,Pleated PP:82℃ |
| Max. operating differential pressure |
Pleated Glass Fiber:3.44bar@121℃,Pleated PP:3.44bar@82℃ |
| Suggestion pressure for filter replacement |
2.5Bar |
Flow Rate and Filtration Area
|
Size
(Diameter*Length)
|
Design Flow
(m3/hr)
|
Maximum Flow
(m3/hr)
|
Filtration Area
(㎡)
|
| 6"*20" |
15 |
40 |
2.6 |
| 6"*40" |
30 |
80 |
5.2 |
| 6"*60" |
45 |
120 |
7.8 |
1. Food and beverage 2. Sea water desalination 3. Power plant condensation 4. Petrochemical engineering
Shanghai Pullner Filtration Technology Co., Ltd. was established in May 2011 with a registered capital of 26 million yuan. It has a 100,000-level purification workshop of 3,000 m² and a local thousand-level purification laboratory. It is a research and development, production and sales of microporous membrane filtration equipment, filtration system in one of the well-known enterprises.
The company's products are mainly used in Microelectronics, Fine chemicals, New energy, Seawater desalination, Biotech, Latoratory and other fields. Covering Liquid crystal panels, Semiconductor chips, High-purity chemicals, Raw materials, Condensate filtration, Reclaimed water reuse more than a dozen industries.
Our company has ISO19001, ISO14001, ISO45001 certificates, we are high-tech enterprise with multiple patent certificates. Approval vendor of Saudi Aramco.
Packing and Shipping:
Packaging and Shipping
Condensate Polishing Filters are packaged and shipped with care to ensure that they arrive in prime condition. Each filter is securely wrapped in bubble wrap and placed in a custom box that is designed to protect the filter during shipping. All boxes are labeled with the appropriate shipping information.
The filters are then placed in a larger box with proper packing material to protect them during transit. The boxes are then placed in a shipping container and the container is sealed and labeled. All shipments are tracked and monitored to ensure the filters arrive safely and on time.
FAQ:
- Q: What is a Condensate Polishing Filter?
- A: The Condensate Polishing Filter from PULLNER, model PHFZ, is a condensate filtration system that utilizes filtration media to remove dissolved solids from condensate and return it to the steam system. It is designed and manufactured in Shanghai, China.
- Q: What are the benefits of using a Condensate Polishing Filter?
- A: The Condensate Polishing Filter from PULLNER, model PHFZ, can reduce the amount of corrosion in the steam system, reduce energy costs, and improve the overall efficiency of the steam system.
- Q: What are the features of the PULLNER Condensate Polishing Filter?
- A: The PULLNER Condensate Polishing Filter, model PHFZ, is designed to be easily installed and maintained. It is constructed of durable stainless steel and is equipped with a replaceable media cartridge. It also features a back-flushing system to keep the filter clean and efficient.
- Q: How often do I need to replace the filter media?
- A: The filter media should be replaced every six months to ensure that the filter operates at maximum efficiency.
- Q: Does the PULLNER Condensate Polishing Filter require special maintenance?
- A: The PULLNER Condensate Polishing Filter, model PHFZ, requires regular back-flushing and filter media replacement to ensure that it operates properly. A service technician should be consulted for more information.
